Brief description
Model: SF7015
Size: 70x70x15mm
Rated Voltage: 5VDC, 12VDC, 24VDC
Bearing Type: Ball Bearing and Sleeve Bearing
Frame and Impeller: Black Plastic PBT UL94V-0
Lead Wires: UL Type (+)Red (-)Black
Operation Temperature/Humidity: -10ºC~70ºC/35%~85%
Unit Weight: 50g
|
Type |
Bearing Type |
Rated Voltage |
Current |
Speed |
Max Air Flow |
Static Pressure |
Noise | ||
|
SF7015B(S)-5L |
√ |
√ |
5 |
0.15 |
2200 |
20.05 |
34.09 |
20.88 |
26 |
|
SF7015B(S)-5M |
√ |
√ |
0.18 |
3000 |
22.38 |
38.05 |
21.37 |
31 | |
|
SF7015B(S)-5H |
√ |
√ |
0.22 |
3500 |
28.67 |
48.74 |
32.15 |
36 | |
|
SF7015B(S)-12L |
√ |
√ |
12 |
0.16 |
3000 |
22.38 |
38.05 |
21.37 |
31 |
|
SF7015B(S)-12M |
√ |
√ |
0.25 |
3500 |
28.67 |
48.74 |
32.15 |
36 | |
|
SF7015B(S)-12H |
√ |
√ |
0.35 |
4200 |
32.31 |
54.93 |
41.66 |
40 | |
|
SF7015B(S)-24L |
√ |
√ |
24 |
0.11 |
3000 |
22.38 |
38.05 |
21.37 |
31 |
|
SF7015B(S)-24M |
√ |
√ |
0.16 |
3500 |
28.67 |
48.74 |
32.15 |
36 | |
Information:
Frame and impellers: Black Plastic PBT UL94V-0
Lead Wires: UL Type(+)red (-)black
Operation Temperature/Humidity: Temperature -10ºC ~ +70ºC Humidity 35% ~ 85%
Unit Weight: 50g
Dimensions:
