Brief description
Model: SF6010
Size: 60x60x10mm
Rated Voltage: 5VDC, 12VDC, 24VDC
Bearing Type: Ball Bearing and Sleeve Bearing
Frame and Impeller: Black Plastic PBT UL94V-0
Lead Wires: UL Type (+)Red (-)Black
Operation Temperature/Humidity: -10ºC~70ºC/35%~85%
Unit Weight: 25g
Parameters:
|
Type |
Bearing Type |
Rated Voltage |
Current |
Speed |
Max Air Flow |
Static Pressure |
Noise | ||
|
SF6010B(S)-5L |
√ |
√ |
5 |
0.15 |
3000 |
11.25 |
19.13 |
14.31 |
25 |
|
SF6010B(S)-5M |
√ |
√ |
0.20 |
3500 |
13.15 |
22.36 |
16.86 |
27 | |
|
SF6010B(S)-5H |
√ |
√ |
0.25 |
4000 |
15.02 |
25.53 |
18.82 |
28 | |
|
SF6010B(S)-12L |
√ |
√ |
12 |
0.08 |
3500 |
13.15 |
22.36 |
16.86 |
27 |
|
SF6010B(S)-12M |
√ |
√ |
0.12 |
4500 |
16.85 |
28.65 |
21.08 |
33 | |
|
SF6010B(S)-12H |
√ |
√ |
0.18 |
5500 |
20.25 |
34.43 |
25.00 |
38 | |
|
SF6010B(S)-24L |
√ |
√ |
24 |
0.08 |
3000 |
11.25 |
19.13 |
14.31 |
26 |
|
SF6010B(S)-24M |
√ |
√ |
0.10 |
3500 |
13.15 |
22.36 |
16.86 |
27 | |
|
SF6010B(S)-24H |
√ |
√ |
0.12 |
4000 |
15.02 |
25.53 |
18.82 |
28 | |
Information:
Frame and impellers: Black Plastic PBT UL94V-0
Lead Wires: UL Type(+)red (-)black
Operation Temperature/Humidity: Temperature -10ºC ~ +70ºC Humidity 35% ~ 85%
Unit Weight: 15g
Dimensions:
